C33000 Low Leaded Brass

C33000 brass tubing, a yellow brass that is both formable and machinable. C330 is only produced in tube form and is generally suitable for minimal corrosive conditions. The lead content prevents from successful welding, but common machine processes include: machining, forming, piercing, and punching.

  • Description
  • Chemical Composition
  • Physical Properties
  • Sizes Available
CATEGORY
ASTMBSENJISDINISOIS
Low Leaded BrassC33000 CW705R  C330



Equivalent Specifications:
Chemical RequirementsDesignation
ISOC330
EuropenCW705R
BS
JISC33000
Russian



Typical Applications :
C33000 Low Leaded Brass
  • Pump Cylinder Liners
  • Power Cylinders Primers
  • Pump Lines
  • J Bends
  • Plumbing Accessories
Chemical Composition :
 CuPbFeSnZn
Min/Max58-610.25-0.700.15(max)0.25(max)Rem
Nominals60.00   40.00



Mechanical Properties:
 CuPbFeZn
Min/Max65.0-68.00.25-0.70.07Rem
Nominals66.000.50-33.5
Fabrication Properties :
Joining TechniqueSuitability
SolderingExcellent
BrazingGood
Oxyacethlene WeldingFair
Gas Shielded Arc WeldingFair
Coated Metal Arc WeldingNot Recommended
Spot WeldFair
Seam WeldNot Recommended
Butt WeldFair
Capacity for Being Cold WorkedExcellent
Capacity for Being Hot FormedPoor
Machinability Rating60
Sizes Available :
Wire1mm To 8mm
Hollow RodsMin Bore Size 20 mm and Max OD 100 mm
Round Rods6mm To 130 mm
Hex5mm To 60mm
Square4mm To 60mm
Flat5mm Min Thickness and max Width 120mm
Profiles / SectionsAS per Customer Drawing
BilletsUp to 200 mm
IngotsAS per Specification
