Threaded Rolling Brass Hollow Rods

Threaded Rolling Brass Hollow Rods

Leaded Brass Hollow Rods / Threaded Rolling Brass Hollow Rods

Threaded Rolling Brass Hollow Rods are high-quality brass tubes designed for excellent cold forming and thread rolling performance. They offer good strength, dimensional accuracy, and superior surface finish, making them ideal for manufacturing threaded components, fasteners, fittings, and precision-engineered parts. These rods ensure smooth processing, consistent quality, and reliable performance in industrial and mechanical applications.

  • Description
  • Chemical Composition
  • Physical Properties
  • Sizes Available
CATEGORY
ASTMBSENJISDINISOIS
Threaded Rolling BrassC35300CZ119CW606N
cw602n
H3260(92) C3501 WCuZn44Pb21639-CuZn43Pb2



Excellent hot and cold workability; good forge ability. Fabricated by bending, coining, coppersmith, drawing and upsetting, hot forging and pressing, knurling, roll threading, shearing, spinning, swaging, and stamping

Typical Applications:

  • Builders Hardware: Drawer Pulls, Hinges, Drawer Handles
  • Consumer: Bicycle Spoke Nipples, Clock and Watch Parts, Clock Plates and Nuts, Key Blanks
  • Fasteners: Nuts, Rivets, Screws
  • Industrial: Ratchets, Instrument Backs, Automatic Screw Machine Parts, Valve Stems, Pinions, Flare Fittings, Couplings, Bearing Cages, Channel Plate, Wheels, Gears, Adapters
  • Other: Engravers Plate
  • Plumbing: Faucet Seats, Faucet Stems, Pipe Fittings, Plumbers Fittings, Plumbers' Brass Goods



Equivalent Specifications

SPECIFICATIONSDESIGNATION
ISOCuZn37Pb2
EuropenCuZn37Pb2
BSCz119

Chemical Composition

 CuFePbZn
Min/Max60.0-63.0.151.5-2.5Rem.
Nominals61.5-2.036.5

Physical Properties

Coefficient of Thermal Expansion11.30 10−6Per °F (68-572 F)
Density0.306 lb/in3 at 68 F
Electrical Conductivity26 %IACS @ 68 F
Electrical Resistivity39.9 ohms-cmil/ft @ 68 F
Melting Point Liquid US1670 F
Melting Point Solid US1630 F
Modulas of Elasticity in Tension15000 ksi
Modulas of Rigidity5600 ksi
Specific Gravity8.470
Thermal Conductivity67 BTU in/hr.ft2.°F @ 68 F

Sizes Available

WIRE1mm To 8mm
HOLLOW RODSMin Bore Size 20 mm and Max OD 100 mm
ROUND RODS/RODS6mm To 130 mm
HEX5mm To 60mm
SQUARE4mm To 60mm
FLAT5mm Min Thickness and max Width 120mm
PROFILES / SECTIONSAS per Customer Drawing
BILLETSUp to 200 mm
INGOTSAS per Specification
